F3300 Parallel
Technical Specifications F3300:
| Frame (conveyor) | anodised extruded aluminium profile die cast aluminium alloy head supports |
|---|---|
| Sidewalls | 1 anodised extruded aluminium profile 1 adjustable in stainless steel |
| Stand supports | castors with brakes |
| Belt | green PVC |
| Pneumatics | pneumatic arm |
| Drive | direct (right side) 3 Phase - 400 V AC / 50 Hz - 0.18 kW asynchronous motor |
| Speed | 3.2 m/min |
| Roller conveyor | gravitational |
| Sensor | 1 photocell/refracting to detect the presence of empty box 3 limit switches (box in the filling position, position of pneumatic arm) |
